Quantity | Per piece |
---|---|
1+ | € 4,73 |
250+ | € 4,18 |
500+ | € 3,66 |
1000+ | € 3,31 |
Article number | 46220 |
Color 2 | Black |
Minimum Order Qty | 2 |
Model | TA |
Seal | Oil Seal |
Brand Types | |
Chicago R | CRWHA1 |
Dichtomatik | WCS |
Ebele | B2SL |
Elring | CS |
Eriks | GVST |
FP Paris | L2P |
Freudenberg | B2 SL |
GOETZE | 824 S |
KACO | DFSK |
Kimman | KCS |
Kramp | DC |
National | 41 |
NOK | TA |
Sealsupply | OS-C11 |
Stefa | DC |
Taiwan | TA |
Vota | CSL |
Design | |
Material | NBR - Nitrile |
Housing Material | Steel |
Material Spring | Steel |
Spring | Yes |
Dust lip | Yes |
Color | Black |
Type | TA |
Design information (Housing bore) | |
Housing Roughness | Ra = 0.8 - 3,2 μm Rz = 6.3 - 16 μm Rmax ≤ 16 μm |
Housing Tolerance | ISO H8 |
Design information (Shaft) | |
Shaft Hardness | min. 45 HRC |
Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
Shaft Tolerance | ISO h11 |
Dimensions | |
Inside Diameter | 109 |
Outer Diameter | 130 |
Height | 15 |
DIN 3760 | 109x130x15 |
Dimensions | 109 x 130 x 15 |
This Oil Seal has the following Dimensions: 109x130x15mm, and the color is Black. The Material of this item is NBR – Nitrile The Material of the house is Steel. The model is Oil Seal TA. The Article number of this Oil Seal 109 x 130 x 15 is 46220. And this item has a minimum order Quantity of 2 Pieces This O-Ring is 130mm and in the color Steel. The Hardness of this Oil Seal 109x130x15 TA NBR - Nitrile Black OSS46220 is 109.The alternative names of the compound are and they are mostly produced by Yes. The O-ring is commonly used in TA and has an operating temperature range from TA to . O-rings 226391 are indicated as 46220 and have a DIN 3771 Size of 130. This item is equal to 109x130x15 and has an Steel Approval. The chemical name of this Oring is Yes.
