| Stock | Delivery time |
|---|---|
| 386 | Shipped in 35 - 42 - Day(s) |
Shipped in 35 - 42 - Day(s)
| Quantity | Per piece |
|---|---|
| 2+ | € 14,99 |
| 100+ | € 11,83 |
| 250+ | € 10,85 |
| 500+ | € 9,75 |
| In stock | Yes, 386 pcs |
| Article number | 47088 |
| Color 2 | Black |
| Minimum Order Qty | 10 |
| Model | DB |
| Type | Oil Seal |
| Brand Types | |
| Dichtomatik | WBD |
| Elring | BD |
| Eriks | M-DUO |
| Freudenberg | B1 DUO |
| GOETZE | 822 D |
| KACO | DFD |
| NOK | DB |
| Sealsupply | OS-D15 |
| Stefa | BK |
| Taiwan | DB |
| Design | |
| Material | NBR - Nitrile |
| Housing Material | Steel |
| Material Spring | Steel |
| Spring | Yes |
| Dust lip | No |
| Type | DB |
| Color | Black |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 0.8 - 3,2 μm Rz = 6.3 - 16 μm Rmax ≤ 16 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 122 |
| Outer Diameter | 152 |
| Height | 21 |
| DIN 3760 | 122x152x21 |
| Dimensions | 122 x 152 x 21 |
This Oil Seal has the following Dimensions: 122x152x21mm, and the color is Black. The Material of this item is NBR – Nitrile The Material of the house is Steel. The model is Oil Seal DB. The Article number of this Oil Seal 122 x 152 x 21 is 47088. And this item has a minimum order Quantity of 10 Pieces This O-Ring is 152mm and in the color Steel. The Hardness of this Oil Seal 122x152x21 DB NBR - Nitrile Black OSS47088 is 122.The alternative names of the compound are and they are mostly produced by No. The O-ring is commonly used in DB and has an operating temperature range from DB to . O-rings 6526432 are indicated as 47088 and have a DIN 3771 Size of 152. This item is equal to 122x152x21 and has an Steel Approval. The chemical name of this Oring is Yes.
