Deliverable from 02-01-2025
All items marked with a * are required.
| Quantity | Per piece |
|---|---|
| 1+ | € 15,06 |
| 50+ | € 11,20 |
| 100+ | € 9,40 |
| 250+ | € 8,31 |
| Article number | 43696 |
| Color 2 | Black |
| Minimum Order Qty | 2 |
| Model | SA |
| Type | Oil Seal |
| Brand Types | |
| B+S | TR-B |
| Chicago R | CRWH1 |
| Dichtomatik | WC |
| Ebele | B2 |
| Elring | C |
| Eriks | GV |
| FP Paris | L2 |
| Freudenberg | B2 |
| GOETZE | 824 N |
| KACO | DKF |
| Kimman | KC |
| Kramp | DB |
| National | 45 |
| NOK | SA |
| Paulstra | EEP |
| Pioneer W | R1 |
| Rolf | RC |
| Sealsupply | OS-C10 |
| Stefa | DB |
| Taiwan | SA |
| Vota | C |
| Design | |
| Material | NBR - Nitrile |
| Housing Material | Steel |
| Material Spring | Steel |
| Spring | Yes |
| Dust lip | No |
| Color | Black |
| Type | SA |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 0.8 - 3,2 μm Rz = 6.3 - 16 μm Rmax ≤ 16 μm |
| Housing Tolerance | ISO H960 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 196.85 |
| Outer Diameter | 234.95 |
| Height | 14.28 |
| DIN 3760 | 196,85x234,95x14,28 |
| Dimensions | 196,85 x 234,95 x 14,28 |
This Oil Seal has the following Dimensions: 196,85x234,95x14,28mm, and the color is Black. The Material of this item is NBR – Nitrile The Material of the house is Steel. The model is Oil Seal SA. The Article number of this Oil Seal 196,85 x 234,95 x 14,28 is 43696. And this item has a minimum order Quantity of 2 Pieces This O-Ring is 234.95mm and in the color Steel. The Hardness of this Oil Seal 196,85x234,95x14,28 SA NBR - Nitrile Black OSS43696 is 196.85.The alternative names of the compound are and they are mostly produced by No. The O-ring is commonly used in SA and has an operating temperature range from SA to . O-rings 56226 are indicated as 43696 and have a DIN 3771 Size of 234.95. This item is equal to 196,85x234,95x14,28 and has an Steel Approval. The chemical name of this Oring is Yes.
