| Stock | Delivery time |
|---|---|
| 560 | Shipped in 35 - 42 - Day(s) |
Shipped in 35 - 42 - Day(s)
| Quantity | Per piece |
|---|---|
| 12+ | € 4,12 |
| 100+ | € 2,38 |
| 250+ | € 2,19 |
| 500+ | € 1,96 |
| In stock | Yes, 560 pcs |
| Article number | 76794 |
| Color 2 | Blue |
| Minimum Order Qty | 10 |
| Model | TC |
| Type | Oil Seal |
| Brand Types | |
| B+S | TR-E |
| Chicago R | HMSA7 |
| Dichtomatik | WAS |
| Ebele | RP |
| Elring | AS |
| Eriks | RST |
| FP Paris | GP |
| Freudenberg | BASL |
| Gaco | FA |
| GOETZE | 827S |
| KACO | DGS |
| Kimman | KAS |
| Kramp | CC |
| National | 32 |
| NOK | TC |
| Paulstra | IEL |
| Pioneer W | R23 |
| Rolf | RP |
| Sealsupply | OS-A11 |
| Stefa | CC |
| Taiwan | TC |
| Vota | ASL |
| Design | |
| Material | NBR - Nitrile |
| Spring | Yes |
| Dust lip | Yes |
| Color | Blue |
| Type | TC |
| Design information (Housing bore) | |
| Housing Roughness | Ra = 1.6 - 6.3 μm Rz = 10 - 20 μm Rmax ≤ 25 μm |
| Housing Tolerance | ISO H8 |
| Design information (Shaft) | |
| Shaft Hardness | min. 45 HRC |
| Shaft Roughness | Ra = 0.2 - 0.8 μm Rz = 1 - 5 μm Rmax ≤ 6.3 μm |
| Shaft Tolerance | ISO h11 |
| Dimensions | |
| Inside Diameter | 35 |
| Outer Diameter | 52 |
| Height | 8.8 |
| Dimensions | 35 x 52 x 8,8 |
| DIN 3760 | 35x52x8,8 |
This Oil Seal has the following Dimensions: 35x52x8,8mm, and the color is Blue. The Material of this item is NBR – Nitrile The Material of the house is . The model is Oil Seal TC. The Article number of this Oil Seal 35 x 52 x 8,8 is 76794. And this item has a minimum order Quantity of 10 Pieces This O-Ring is 52mm and in the color . The Hardness of this Oil Seal 35x52x8,8 TC NBR - Nitrile Blue OSS76794 is 35.The alternative names of the compound are and they are mostly produced by Yes. The O-ring is commonly used in TC and has an operating temperature range from TC to . O-rings 6558141 are indicated as 76794 and have a DIN 3771 Size of 52. This item is equal to 35x52x8,8 and has an Approval. The chemical name of this Oring is Yes.
